BottomSheetDialog

A library for using the bottom sheet dialog in iOS.

• AutoLayout is supported.
• You can apply cornerRadius to Sheet.
• There are many customizable attributes.
• Handling did Tap event using delegate.
• Easy and simple to use.

Usage

1. init and set delegate

let sheet = BottomDialogView(titles: ["delete",
                                          "cancel"],
                             images: [UIImage(named: "trash")!
                                            .withRenderingMode(.alwaysOriginal),
                                      UIImage(named: "xmark")!
                                            .withRenderingMode(.alwaysOriginal)])
    sheet.delegate = self

2. Set Attributes

    sheet.titleFont = UIFont.systemFont(ofSize: 14, weight: .regular)
    sheet.sheetHeight = 56
    sheet.imageSize = CGSize(width: 30, height: 30)
    sheet.removeFromSuperviewWhenDidTap = true // default value is false
    sheet.sheetCornerRadius = 14
    sheet.sheetBottomPadding = view.safeAreaInsets.bottom
    sheet.sheetBorderWidth = 0.5
    sheet.sheetBorderColor = .gray

Here are all of the customizable attributes and their default values:

var sheetCornerRadius: CGFloat = 0
var sheetCornerRadiusOnlyTop = false
var sheetBorderWidth: CGFloat = 0
var sheetBorderColor: UIColor = .lightGray
var sheetHeight: CGFloat = 56
var sheetPadding: CGFloat = 0
var imageLeadingPadding: CGFloat = 16
var titleLeadingPadding: CGFloat = 20
var titleColor: UIColor = .black
var titleFont: UIFont = .systemFont(ofSize: 14, weight: .bold)
var titleAlignment: NSTextAlignment = .natural
var viewBackgroundColor: UIColor? = .black.withAlphaComponent(0.7)
var sheetBackgroundColor: UIColor = .white
var removeFromSuperviewWhenDidTap = false
var sheetBottomPadding: CGFloat = 0
lazy var imageSize: CGSize = CGSize(width: 28, height: 28)

But you can use the default settings without specifying anything.

3. Add subview and show()

view.addSubview(sheet)
sheet.show()

4. Event handling with delegate method

extension ViewController: BottomDialogDelegate {
  func didTapSheet(title: String, tag: Int) {
    switch title {
    case "delete":
      print("delete")
    default:
      print(title)
    }
  }
}

If the removeFromSuperviewWhenDidTap setting is not set to true, you must manually call removeFromSuperview().

Requirements

iOS version >= 11.0
Swift version >= 5.0

Installation

BottomSheetDialog is available through CocoaPods. To install it, simply add the following line to your Podfile:

pod 'BottomSheetDialog'

Author

wanderingfairy, [email protected]

License

BottomSheetDialog is available under the MIT license. See the LICENSE file for more info.
